PRODUCTS

PC Hammer Crusher

【Max Feed】 ≤1000mm 【Discharging Opening】 0-60mm 【Capacity】 20-680t/h
编号
A011
Affiliate classification
Brief Introduction
The hammer crusher is used widely for the secondary and fine crushing of mid-hard material.
Applications
Suitable for medium and fine crushing of medium hardness materials in cement, chemical industry, electric power, metallurgy
Suitable Material
It is widely used in cement, chemical, electric power, metallurgy etc.
没有此类产品
I want to make an inquiry
Details

Advantages

The electrical motor drives the crusher shaft and make the movable jaw move upwards and downwards. This movement would trigger the toggle plate to push the movable jaw forward and backwards.When the movable jaw moves forth toward the fixed jaw, materials in the crushing cavity will be squashed or chopped. And the movable jaw travels back, the chopped or squashed materials which met the requirement will be discharged from the outlet. Since the motor keeps working, the crusher will crush and discharge periodically to achieve mass production

Model

Feed particle size≤(mm)

Discharge gap

(mm)

Production

 (t/h)

Motor Power

(KW)

PCφ800*800

500

≤10-60

40-60

45

PCφ800*1000

500

≤10-60

50-80

55

PCφ1000*1000

550

≤10-60

60-100

75

PCφ1000*1200

550

≤10-60

80-120

90(45+45)

PCφ1000*1400

550

≤10-60

100-150

110(55+55)

PCφ1000*1800

550

≤10-60

100-160

132

PCφ1200*1400

550

≤10-60

130-180

132(75+75)

PCφ1200*1500

550

≤10-60

150-200

132(75+75)

PCφ1200*1800

550

≤10-60

180-280

200

PCφ1500*1800

650

≤10-60

180-400

200(110+110)

PCφ1500*2000

650

≤10-60

200-450

250-280

PCφ1800*2000

700

≤10-60

240-680

500(250+250)

PCXφ1400*1200

100

≤12

80-120

160-200
