VSI Series Vertical Shaft Impact Crusher

【Max Feed】 ≤50mm 【Capacity】 60-640t/h
编号
A013
Brief Introduction
VSI series vertical shaft impact crusher is the new generation of sand making machine.
Applications
Widely used in crushing and reshaping of metallic and non-metallic ore, building materials.
Suitable Material
Rock, abrasive, fire-proof material, cement clinker, comprised, iron ore, concrete aggregate etc.
没有此类产品
I want to make an inquiry
Details

Advantages

The material falls vertically from the upper part of the machine into the impeller of high-speed rotation. Under the action of high-speed centrifugal force, the material that is shunted around the impeller in another part of the machine produces high-speed impact and pulverization. After the materials collide with each other, they will be in the impeller and Between the casings, the vortex is formed by multiple collisions, friction and pulverization, and is discharged straight from the lower part to form a closed circuit for multiple cycles, and the required size of the finished product is controlled by the screening device.

Model

Maximum feed port size

(mm

Processing capacity

(t/h)

Spindle speed

(r/min)

 Power

 (kw)

Dimensions

(L*W*H)

(mm)

Soft material

Hard material

Waterfall and center feeding

Whole center feed

VSI-7611

35

30

120-180

60-90

1710-1900

55×2

3600*2248*2533

VSI--8515

45

35

200-260

100-130

1520-1720

90×2

4378*2350*2667

VSI-9526

45

40

300-380

150-190

1350-1530

132×2

4640*2650*2800

VSI-1140

50

45

450-520

225-260

1170-1350

200×2

5000*2700*3300

VSI-1145

50

45

500-640

250-360

1100-1310

220×2

5100*2790*3320
